Control your production floor from a distance. The expansive 19-inch touchscreen provides an intuitive workspace, while built-in Wi-Fi and Ethernet allow for remote job programming, production monitoring, and seamless integration with your workshop's digital ecosystem.
Cut downtime and waste. With a backgauge speed up to 32m/min, the machine positions rapidly. Its intelligent planning system automatically calculates the most efficient cutting layout based on your stock and product sizes, generating cutting instructions and animations to improve paper utilization significantly.
Gain insights into your productivity. The built-in system clearly records daily cutting counts and order data per operator, automatically compiling output statistics. This data-driven approach helps in managing workshop efficiency and labor performance.
Handle demanding jobs with confidence. Designed for powerful cutting of thick printed and packaging materials, the machine incorporates a comprehensive safety suite including electronic locks and safety photocells, ensuring protection meets high-production demands.
Top 6 reasons the S19 is the smartest investment for high-volume, network-driven print shops.
High-speed positioning cuts production cycle time by up to 30% versus standard cutters.
Built-in Wi-Fi & Ethernet for remote job submission, MIS/ERP integration, and live monitoring.
Larger, brighter display optimized for complex multi-cut programs and visual previews.
Auto-calculates the most efficient layout, increasing paper utilization by 5-12%.
Automatically logs daily cutting counts and output per operator for data-driven management.
Precision hydraulic control delivers dynamic cutting stability under high-speed cycles.
Safety standards and advanced electrical integrations for this series
Mechanically secures the knife bed during non-cutting cycles to prevent blade slippage, ensuring absolute operator safety.
German-engineered plug-in valve technology delivers smooth, impact-free clamping and precise cutting force with maximum stability.
High-performance pump ensures constant hydraulic pressure, rapid response times, and exceptional durability for continuous operation.
Provides highly precise control over hydraulic flow, ensuring dynamic cutting stability under high-speed automated cycles.
Intuitive human-machine interface allowing real-time program adjustments, automated error diagnostics, and effortless machine control.
Industry-leading infrared sensors actively monitor the workspace, instantly triggering an emergency stop if any obstruction is detected.
High-precision servo motor ensuring fast, stable, and accurate paper positioning with rapid acceleration and deceleration.
HPM's customized logic controller provides powerful anti-interference capabilities and precise synchronization of all automated functions.
Heavy-duty construction designed for longevity and cutting precision.
Adopted to ensure high-precision assembly process, significantly improving the overall rigidity and stability of the cutter.
Large size worm gear provides superior cutting force and guarantees a powerful, stable cutting transmission.
The knife bed adopts a long slotted hole design, which is extremely convenient for quick knife changes and adjustments.
If a safety component fails or bolts loosen, the critical knife bed puller halts the machine instantly, preventing damage and injury.
The fully enclosed air cushion device makes paper movement very light and smoother.
The paper pusher is linearly double guide rail guided and ball screw driven for smooth operation and precise positioning.
Integrated seamless working table with chrome-plated surface and good structural strength.
Click a width below to view recommended applications and sizing guidance.
HPM S19 cutters come in six industrial cutting sizes.
36.2" / 92cm
45.3" / 115cm
53.9" / 137cm
66.1" / 168cm
74.0" / 188cm
Recommended applications
Recommended applications
Recommended applications
Recommended applications
Recommended applications
When selecting cutter width, consider not only the sheet long edge but also the diagonal length when the stack is rotated 90° on the table. For example, frequent 90° rotation of 102cm full sheets typically calls for at least a 137cm (53.9") machine to preserve squaring and jog clearance.
| Spec / Model | 92 | 115 | 130 | 137 | 168 | 188 |
|---|---|---|---|---|---|---|
| Max. Cutting Width (cm) | 92 | 115 | 130 | 137 | 168 | 188 |
| Max. Cutting Height (cm) | 12 | 16.5 | 16.5 | 16.5 | 16.5 | 16.5 |
| Min. Cutting Size (without plate) (cm) | 2.5 | 3 | 3 | 3 | 3 | 3 |
| Front Table Length (cm) | 63.2 | 71.5 | 73 | 73 | 75 | 75 |
| Max. Clamp Pressure (N) | 30000 | 40000 | 40000 | 45000 | 60000 | 70000 |
| Max. Cutting Speed (time/min) | 45 | 46 | 46 | 46 | 46 | 46 |
| Main Motor (KW) | 3 | 4 | 4 | 4 | 8.5 | 8.5 |
| Net Weight (Kg) | 2300 | 3700 | 3900 | 4100 | 6200 | 6600 |
Refer to the diagram and table below to prepare your factory floor space before installation.
| Model | Unit | A | B | C | D | E | F | G |
|---|---|---|---|---|---|---|---|---|
| 92 | cm | 215 | 232 | 92 | 90 | 157 | 60 | 70 |
| inch | 84.6 | 91.3 | 36 | 35.4 | 61.8 | 23.6 | 27.6 | |
| 115 | cm | 259.7 | 265 | 115 | 90 | 172 | 70 | 75 |
| inch | 102.2 | 104.3 | 45 | 35.4 | 67.7 | 27.6 | 29.5 | |
| 130 | cm | 275.5 | 280 | 130 | 90 | 172 | 70 | 75 |
| inch | 108.5 | 110.2 | 51.2 | 35.4 | 67.7 | 27.6 | 29.5 | |
| 137 | cm | 285.5 | 287 | 137 | 90 | 172 | 70 | 75 |
| inch | 112.4 | 113 | 54 | 35.4 | 67.7 | 27.6 | 29.5 | |
| 168 | cm | 313 | 368 | 168 | 90 | 178 | 75 | 100 |
| inch | 123.2 | 144.9 | 66.1 | 35.4 | 70 | 29.5 | 39.4 | |
| 188 | cm | 346 | 388 | 188 | 90 | 178 | 75 | 100 |
| inch | 136.2 | 152.8 | 74 | 35.4 | 70 | 29.5 | 39.4 |
After integrating the S19 with our MIS system, we eliminated almost all manual programming. The 32m/min backgauge speed alone cut our average job time by nearly a third — the ROI was clear within the first quarter.
Leveraging top-tier brands to ensure long-term industrial durability. For export markets, CE-compliant options are available.
| No. | Name | Brand, specification & model | CE Standard (Optional) |
|---|---|---|---|
| 1 | Background LCD | 19'' Color touch Interface | - |
| 2 | PLC | HPM | Panasonic |
| 3 | Backgauge position motor | INOVANCE servo motor | Panasonic |
| 4 | Pick-up | FOTEK | - |
| 5 | Limit switch | TE | - |
| 6 | Guarding motor | TE | - |
| 7 | Air switch | TE | - |
| 8 | AC Contactor | TE | - |
| 9 | Miniature relay | IDEC | - |
| 10 | Switching power supply | TE | - |
| 11 | Power switch | CANSEN | - |
| 12 | Press-button | TE | - |
| 13 | Ball screw | High accurate (HIWIN) | - |
| 14 | Linear guider | High accurate double linear Guides (JSM) | - |
| 15 | Hydraulic system | Combination Valve (VIS) | WESSEL (Germany) |
| 16 | Oil Pump | RYAN | BONDIOLI (Italy) |
| 17 | Main Bearing | NSK | - |
| 18 | Work Table | Slotless and plated chromium | - |
| 19 | Photocell | Sheng da | AB (America) |
| 20 | Knife | HSS | - |
| 21 | Closing cover | Standard equipment | - |
